This 5-ton hydraulic bottle jack is a robust, high-performance lifting device engineered for safe and efficient vehicle maintenance. Built with industrial-grade materials and precision hydraulic components, it delivers reliable lifting power for cars, trucks, SUVs, and light commercial vehicles, supporting up to 5 tons (10,000 lbs) of load capacity. Whether you’re changing a flat tire, performing brake repairs, or accessing the undercarriage for routine maintenance, this jack provides the strength and stability you need.
Key Features
5-Ton Heavy-Duty Lifting CapacityThe jack is rated for a maximum load of 5 tons, making it suitable for most passenger vehicles and light-duty trucks. Its hydraulic system generates consistent, controlled lifting force, ensuring safe and steady elevation without sudden drops or instability.
Sturdy & Durable ConstructionThe body is made of high-quality cast iron with a corrosion-resistant red finish, ensuring long-term durability even with frequent use. The wide, reinforced base design lowers the center of gravity, significantly improving stability during lifting operations to prevent tipping.
Hydraulic Operation with Two-Piece HandleThe jack uses a hydraulic cylinder to convert manual pumping into powerful lifting force. The included two-piece pump handle provides mechanical advantage, requiring minimal effort to lift heavy loads. The handle is easy to assemble and disassemble for compact storage.
Adjustable Lifting HeightThe jack features an adjustable screw top extension to fine-tune the initial height, allowing it to reach the vehicle’s chassis more easily. The hydraulic ram extends smoothly, providing sufficient lift range for most tire changes and undercarriage repairs.
Safety & Convenience DesignBuilt with safety in mind, the jack includes a pressure relief valve to prevent overloading, protecting both the jack and the user from damage. The compact bottle-style design makes it easy to store in car trunks, garages, or workshops without taking up much space.
Model No. Packing Size(cm) PCS/ Carton G.W./N.W.(kgs)
ST612826 57*21*19 10 2.9/1.9
ST612827 57*21*19 10 3.1/2.1
ST612828 59.5*13*21 5 3.5/2.5
ST612829 64.5*14*23 5 4.1/2.1
ST612830 64.5*14*23 5 4.8/3.8
ST612831 60*16*24 4 6.5/5.5
ST612832 31*16*23.5 2 7.1/6.1
ST612833 33*17*26 2 8.0/7.0
ST612834 37*18*27 2 10.0/9.0
ST612835 19*20*28 1 14.5/13.5
ST612836 32*37*40 1 69/68
