12V DC 3000lbs ATV Electric Winch with Steel Cable & Mounting Bracket

Pull, Speed, Amperes, Volts(First Layer)

Line Pull (lbs./kg)    Line Speed FPM(m/min)    Motor (Amps)

0    10.8ft (3.3m)    12

1,000(454)    8.2ft (2.5m)    60

2,000(907)    3.6ft (1.1m)    100

3,000(1361)    2.6ft (0.8m)    130

Line Pull And Rope Capacity In Layer

Layer    Rated Line Pull (Ibs./kgs)    Total Rope On Drum (ft/m)

1    3000(1361)    4.9(1.5)

2    2320(1052)    11.5(3.5)

3    1890(858)    19.3(5.9)

4    1590(720)    28.5(8.7)

5    1380(620)    40.0(12.2)

2pcs in a carton

Packing size:34*29*15.8CM

N.W/G.W.7/8KG

Qty for 20'container:3594pcs

Qty for 40'container:7446pcs

Qty for 40'HQcontainer:8728pcs
